MODEL 160P STACKER – Quick Reference Guide 5

CHAPTER 3: MODEL 160P STACKER - BASIC OPERATION

3.1 STACKER COMPONENT DESCRIPTION

Adjustable “Top of

Stack” Lever

Removable Stack

Cartridge

Stacker Jam Sensor

Sliding Stack Weight

Pinch Roller

Engagement Release

Lever

Printer Engagement

Bracket

Cartridge Backstop
